Epson LabelWorks LW-700 User Manual

1. To add a frame, press the key.
You see the Edit menu on the display.
2. Use the key to highlight Frame & Table and press the key.
3. Highlight Frame and press the key.
You see the frames on the display.
4. Use the key to highlight the number of the frame you want, or enter the frame number to jump
directly to a frame.
5. Press the key to select the frame you want.
6. Highlight Whole label or This block and press the key.
Note: You can add a frame either before or after adding the text to your label, but the frame will not
appear on the preview until you add text.
Available Frames
Parent topic: Creating Labels Using the Keyboard
Related references
Label Format Settings
27

Epson LabelWorks LW-700 Specifications

General

Print technology	Thermal transfer
Maximum resolution	180 x 180 DPI
Maximum print height	18 mm
Maximum printing width	24 mm
Ethernet LAN	No
PC connected	Yes
Optional connectivity	USB 2.0
Country of origin	China
Battery type	AA
Power consumption (off)	1.44 W
Power consumption (standby)	6.99 W
Number of batteries supported	6
Power consumption (PowerSave)	0.22 W
Minimum storage drive space	100 MB
Compatible operating systems	Microsoft Windows XP/7/8\\r Mac OS 10.4+
Display	LED
Product color	White
Keyboard layout	QWERTY
Number of fonts	14
Number of styles	16
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Number of printing lines (max)	8
Sustainability certificates	ENERGY STAR
Pallet width	800 mm
Pallet height	1770 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	90 pc(s)
Minimum order quantity	5 pc(s)
Quantity per pallet (UK)	120 pc(s)
Quantity per pallet layer	15 pc(s)
Quantity per pallet layer (UK)	20 pc(s)
Package depth	320 mm
Package width	270 mm
Package height	140 mm
Package weight	1964 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	235 mm
Width	180 mm
Height	80 mm
Weight	770 g
