• Include a label on both ends of the cable.
• When adhering a flag label to the cable, loop the label around the cord loosely and stick the ends of
the label together, then move inward toward the cable. This makes it easier to align the ends.
• If space for a flag label is limited, use narrower tapes, such as 3/8 inch (9mm) and 1/4 inch (6mm).
• Use multiple wrapped labels on a single cord to include more information.
Creating Cable Labels
Parent topic: Creating Special Format Labels Using the Keyboard
Creating Cable Labels
Two styles of cable labels are available: flag and wrapped. You can use either horizontal or vertical text
on both label styles.
1. Press the key.
2. Select one of the following and press the key:
• Wrap:V
• Wrap:H
• Flag:V
• Flag:H
3. Select the length of the label, or select Auto to have the length vary by the label text.
4. Press the key.
5. Enter the text for your label.
Parent topic: Cable Labels
Creating Equipment Management Labels
The equipment management label format provides a 4-line, 2-column table with default text. You can
modify the defaults as necessary.
42
