Epson LabelWorks LW-700 User Manual

6. Select any of the tabs to display the available options.
7. Select the options you want.
8. When you are finished, click OK.
Parent topic: Designing Labels With Label Editor
Related tasks
Working With Blocks in Label Editor
Inserting Text Art in Label Editor
You can add curves or other special effects to text on your labels and ribbons.
1. Open the Insert menu and select Text Art.
You see this window:
2. Enter the text for the art, then select the Font, Size, Style, and Text Alignment options you want to
use.
3. Click the Shape tab.
73

Epson LabelWorks LW-700 Specifications

General

Print technology	Thermal transfer
Maximum resolution	180 x 180 DPI
Maximum print height	18 mm
Maximum printing width	24 mm
Ethernet LAN	No
PC connected	Yes
Optional connectivity	USB 2.0
Country of origin	China
Battery type	AA
Power consumption (off)	1.44 W
Power consumption (standby)	6.99 W
Number of batteries supported	6
Power consumption (PowerSave)	0.22 W
Minimum storage drive space	100 MB
Compatible operating systems	Microsoft Windows XP/7/8\\r Mac OS 10.4+
Display	LED
Product color	White
Keyboard layout	QWERTY
Number of fonts	14
Number of styles	16
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Number of printing lines (max)	8
Sustainability certificates	ENERGY STAR
Pallet width	800 mm
Pallet height	1770 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	90 pc(s)
Minimum order quantity	5 pc(s)
Quantity per pallet (UK)	120 pc(s)
Quantity per pallet layer	15 pc(s)
Quantity per pallet layer (UK)	20 pc(s)
Package depth	320 mm
Package width	270 mm
Package height	140 mm
Package weight	1964 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	235 mm
Width	180 mm
Height	80 mm
Weight	770 g
