Chapter 3 Disassembly and Assembly
Rev. A
3-1
7
SHAFT, LEVER, PULLEY, DRIVEN
LEVER, PULLEY, DRIVEN
CAP, LEVER
HOLDER, ADJUST, LEVER
TENSION SPRING, 14.5
Hexagonal Nut
Adjust Lever
Figure 3-14. CARRIAGE ASSY. Removal (1)
GUIDE, CR
CR GUIDE SHAFT
CARRIAGE ASSY.
Figure 3-15. CARRIAGE ASSY. Removal (2)
