Epson LX-1170 User Manual

3-12
Using the Printer Software
The monitoring settings are shown below.
EPSON Status
Monitor 3
You can access the EPSON Status Monitor 3 utility
when you click this button. To monitor the printer,
make sure the Monitor the printing status check box
is selected.
Monitoring
Preferences
Click this button to open the Monitoring
Preferences dialog box where you can make
settings for the EPSON Status Monitor 3 utility.
Paper/Output Check the Paper Size, Orientation, and Paper
S o u rc e s et t i ng s you ma d e o n t he P a g e S e tu p me n u
and change them if necessary. Select the setting
and then choose an option from the Change
Setting list box.
Halftone Click this button to set the brightness and contrast,
input the RGB gamma, or make other settings. The
Halftone Color Adjustment dialog box appears. For
details, click the Help button in this dialog box.
Settings Explanations
EPSON Status
Monitor 3
You can access the EPSON Status Monitor 3 utility
when you click this button. To monitor the printer,
make sure the Monitor the printing status check box
is selected.
Monitoring
Preferences
Click this button to open the Monitoring
Preferences dialog box where you can make
settings for the EPSON Status Monitor 3 utility. For
more information, see “Setting up EPSON Status
Monitor 3” on page 3-13.
Settings Explanations

Epson LX-1170 Specifications

Print Speed

high speed draft 15 CPI	337 cps
high speed draft 12 CPI	337 cps
high speed draft 10 CPI	300 cps
high speed draft 20 CPI condensed	300 cps
high speed draft 17 CPI condensed	321 cps

Power

rated voltage	AC 120V or AC 220~240V
rated frequency	50~60Hz
power consumption	23W

Environmental Conditions

temperature	5~35˚C
humidity	10~80% RH
acoustic noise	49dB (A)

Reliability

MVBF (Mean Print Volume Between Failure)	12 million lines
MTBF (Mean Time Between Failure)	6000 POH
print head life	400 million strokes/ wire

Weight and Dimensions

width	546 mm
depth	275 mm
height	163 mm
weight	6.3 kg
