104 Options and Consumables
Roll Paper Holder
The optional roll paper holder (#8310) allows you to use your
printer with 8.5 inch (216 mm) roll paper. Follow these steps to
install and use the roll paper holder:
1. Turn off the printer and remove the paper guide.
2. Position the roll paper holder beneath the printer as shown
below. Fit the two holes in the base onto the two positioning
pegs on the bottom of the printer.
w
Caution:
Be careful to avoid dropping the roll paper holder when lifting the
printer. Only the printer’s weight holds it in place.
3. Push the paper release lever to the single-sheet position.
4. Cut the leading edge of the roll paper straight across. Slide
the roll paper holder shaft through the center of the roll.
To Next Page
