Epson LX-300+ Reference Guide

118 Product Information
Labels: bottom entry
Roll paper: rear entry with optional roll paper holder
Label size 15/16 × 2.5 inches (23.8 × 63.5 mm)
minimum
0.1 inch (2.5 mm) corner radius,
minimum
Backing sheet width 4.0 to 10.0 inches (101.6 to 254 mm)
Backing sheet length 4.0 to 22.0 inches (101.6 to 558.8 mm)
Backing sheet
thickness
0.0028 to 0.0035 inch (0.07 to 0.09 mm)
Total thickness 0.0063 to 0.0075 inch (0.16 to 0.19 mm)
Label weight 17 lb (64 g/m²)
Width 8.5 inches (216 mm)
Thickness 0.0028 to 0.0035 inch (0.07 to 0.09 mm)
Weight 14 to 22 lb (52 to 82 g/m²)

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
