Epson LX-300+ Reference Guide

Options and Consumables 99
4. Hold the cut-sheet feeder with both hands and press on the
latch levers. Fit the notches in the cut-sheet feeder over the
mounting posts on the printer. Releasing the latch levers
locks the cut-sheet feeder in place.
5. Slide the left paper guide so it is aligned with the triangle
mark. Then slide the right paper guide to roughly match the
width of your paper. Slide the paper support midway
between the paper guides.

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
