93
Appendix
Paper Specifications
Paper type Thermal paper
Form Roll paper
Size Paper width 57.5 ± 0.5 mm {2.26 ± 0.02 in.}
Roll width when taken up 58 ± 0.5 mm {2.28 ± 0.02 in.}
Roll outside diameter 40 mm {1.57 in.} at maximum
Roll core outside diameter At least 18 mm {0.71 in.}
Roll core inside diameter At least 12 mm {0.47 in.}
Roll core width Must be the same as the paper width or smaller than the paper width
with a difference of 1 mm {0.04 in.} or less.
Paper thickness 75 μm at maximum, 50 μm at minimum
Specified original paper TF50KS-EY, TF60KS-E (NIPPON Paper Industries Co., Ltd.)
PD160R, PD190R (OJI Paper Mfg. Co., Ltd.)
P220AGB-1 (Mitsubishi Paper Mills Limited.)
AP45KS-ND, AP50KS-ND (Jujo Thermal Oy)
P5047(55), P5047(46) (Mitsubishi HiTec Paper Europe GmbH)
KT55FA, KT48FA, KT55PF, KT48PF (Papierfabrik AugustKoehler SE)
• Paper must not be pasted to the roll paper core.
• Use of thermal paper with a pre-printed recording surface should be avoided. Using it can cause
the thermal head to stick to the thermal paper surface during printing, and cause printing
failure and other problems. The pre-printing also can result in reduced print density. When using
thermal paper with a pre-printed recording surface, pre-printing should be done in accordance
with the conditions (ink type, printing and other conditions) recommended by the paper
manufacturer, and the thermal paper should be checked to ensure that there is no faulty
printing, loss of print density, or other problems.
It is recommended to mark the end of the roll with a red line so that the end of the roll can be
recognized.
