EPSON Perfection 1670 Photo/Perfection 1270 Revision B
APPENDIX Overview 36
Table 5-7. I/F Board J7
Table 5-8. CCD Board J2
Table 5-9. Inverter Board CN1
Table 5-10. TPU Inverter Board CN2
Pin No. Signal I/O
1 VCC5V O
2 GND -
3TPO15V O
4 LOD O
5GND -
6 SO I
7SI O
8 SCK O
Pin No. Signal I/O
1L15V O
2 GND -
Pin No. Signal I/O
1LAMP O
2 LAMP O
Pin No. Signal I/O
1LAMP O
2 LAMP O
