Removing a Hard Disk Drive From the Mounting
Bracket
Follow these steps if you need to remove the hard disk drive
from the bracket
1. Disconnect the cables from the back of the hard disk drive
and diskette drive in the bracket. Grasp the connectors and
pull them straight out so you do not bend the pins; do not
pull on the cables.
2. Remove the screws securing the bracket to the drive bay and
brace.
3. Slide the bracket and drive away from the front of the
computer and lift them out.
4. Remove the screws securing the hard disk drive to the
bracket and slide the drive out of the bracket.
5. Replace the diskette drive and bracket following the
instructions on page 4-8.
4-14 Installing and Removing Drives
