Epson SC-S70600 Series User Manual

O
Hold the center of the media and raise the media
loading lever.
P
Pull the media straight to the center of the after
heater.
❏ Do not pull the media with both hands. This
could cause the media to skew or move
around.
❏ The labels on the after heater are not used
when media is loaded. If it is adjusted to
forcefully, the media way move around or
become loose.
Q
Lower the media loading lever to hold the media
in place.
R
Set the media holding plates at both sides of the
media.
Sliding media holding plates
While holding the tabs of the media holding
plates on both sides, move the plate to the edge of
the media.
Adjust so that the edge of the media is aligned to
the center of the round holes in the media
holding plates.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Basic Operations
61
