Using the Large-Capacity
Paper Basket (SC-T7200D
Series/SC-T5200D Series)
The large-capacity paper basket collects paper from the
printer, preventing it falling to the floor and becoming
creased or dirty.
If a single sheet is to be collected, any size or type of
paper can be collected after printing.
The following chart shows the maximum paper lengths
that can be collected.
Maximum paper length when a single sheet is
collected
Large-capacity position Approx. 1,580 mm
Compact position Approx. 1,189 mm
Note:
Close the paper basket before printing banners or other
documents that exceed the maximum length. Before the
paper ejected from the printer touches the floor, we
suggest that you take it in both hands close to the paper
eject guides and continue to lightly support it until
printing is complete.
When you print in line drawing mode on a plain paper
roll, this basket can collect various sizes of sheets
*
up to
A1 Landscape.
When collecting multiple sheets, use the paper basket in
the large-capacity position.
Adjusting the PositionU “Adjusting the Position” on
page 49
* Up to 20 sheets under normal temperatures. Note
that the number of sheets that can be collected is
reduced by work environment, images to be printed,
and other factors. If too many sheets are collected, a
paper jam may occur.
c
Important:
If you collect consecutive sheets of A1 Portrait plain
paper or larger, stains, folds, or other damage to the
printed sheets may occur.
Storing and Adjusting the
Position
Storing
Close the large-capacity paper basket before loading
paper or moving the printer.
Adjusting the Position
Compact position
Drop down the basket to the position in which it is fixed
by the lower protrusions of the left and right frames.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Basic Operations
49
