Epson Stylus Color 440

EPSON Stylus COLOR 440, 640, and 740 Appendix
182
525 Spacer, Fixing, Roller, PF
526 Spacer, Fixing, Roller, PF; B
527 Crescent Ring
528 Plain Washer 12.2
×
0.5
×
15
529 Roller Assembly, Paper Eject
530 Bushing, 6
531 Retaining Ring, Type-E (4)
532 Spur Gear, 36
533 Spur Gear, 11
534 Plain Washer, 4.1
×
0.5
×
6.5
535 Paper Guide, Front Platen
536 Grounding Spring, Paper Eject
538 Frame, Paper Eject
539 Holder, Star Wheel, Right
540 Holder, Star Wheel, Left
541 Holder, Star Wheel, Front
542 Star Wheel Assembly, 8 (Natural)
543 Star Wheel 8; B
544 Bar Spring, Star Wheel
545 Paper Guide, Upper Pinch Roller Assembly
546 Paper Guide, Right
547 Paper Guide, Left
548 Shaft, Paper Guide, Upper
549 Shaft, Roller, Driven
550 Roller, Driven; D
551 Torsion Spring, 117.6
552 Board Assembly, PE Paper End (PE) Sensor
553 Holder, PE Paper End (PE) Sensor Support
554 Lever, PE
555 Torsion Spring, 0.22
556 Sheet, Guide Plate, Cable
Table A-27. Parts List for the Stylus COLOR 440 and 640
(continued)
Part # Parts Price List Description Common Name
557 Guide Plate, Cable
558 Sheet, Cable
559 Detector, HP Carriage Home Position (HP)
Sensor
560 Carriage Assembly
561 Lever, Adjust Head Angle Adjusting Lever
562 Grouding Plate, Head
563 Oil Pad
564 Slider, CR
565 Timing Belt
566 Shaft, CR, Guide Carriage (CR) Guide Shaft
567 Pulley Assembly, Driven Tensioning Pulley
568 Holder, Pulley, Driven Pulley Holder
569 Compression Spring, 19.6
570 Lever, PG
571 Lever, PG, Sub
572 Torsion Spring, 63.7
573 Combination Spring, 6, 34.4
574 Combination Spring, 8, 30
576 Absorber, Slider, Cap
577 Bushing, Fixing, Combination Gear
578 Push Nut, 2
579 Harness, HP
580 Harness, PE
581 Harness, ASF
586 CBS-Tite Screw
587 CBS-Tite Screw, M3
×
6
588 CBS-Tite (P4) Screw, 3
×
6, F/Zn
589 Leaf Spring, 6.2
×
0.15
×
11
590 Plain Washer, 2.6
×
0.5
×
8
700 Printhead
Table A-27. Parts List for the Stylus COLOR 440 and 640
(continued)
Part # Parts Price List Description Common Name
