EPSON Stylus COLOR 440, 640, and 740 Appendix
188
Table A-28. Parts List for the Stylus COLOR 740
Part # Parts Price List Description Common Name
100 Housing
101 Cover, Printer
102 Paper Support Assembly
103 Stacker Assembly Paper Output Tray
104 Panel Assembly
105 Shield Plate, Panel
106 Housing, Panel, Left
107 Button, P/S; B
108 Groundign Plate
109 Cover, Shield Plate, M/B, Right
111 Cover, Cable Cable Holder
112 Cover, Inlet, Upper; B
113 Cover, Inlet, Lower; B
114 Shiled Plate, M/B
115 Logo Plate
116 Housing, Sub, Right; B
117 Housing Sub, Left; B
119 Foot
121 CP Screw, M3
×
6
122 CBS-Tite Screw, M3
×
6
123 CB(O) Screw, 4
×
5, F/Zg
124 CBS-Tite Screw, M3
×
10
125 CBP-Tite Screw, M3
×
8, F/Zn
126 CBP-Tite Screw, M3
×
10, F/Zn
128 Mini Clamp Cable Hook
131 Cover, Cable; B
132 Lock, Stacker
133 Compression Spring, 2.94
134 Spacer, Housing
135 Spacer, Housing, Panel
180 Label, Caution 1
181 Label, Accessory
183 Label, Lever Cartridge, Black
184 Label, Lever Cartridge, Color
200 Board Assembly, Main
300 Board Assembly, Power Supply
330 Harness
400 Power Cable Assembly
450 Board Assembly, Panel
500 Printer Mechanism
501 Frame Assembly, Left
502 Motor Assembly, PF Paper Feed (PF) Motor
503 Spur Gear, 23.2
504 Combination Gear, 16, 40.8
505 Frame, Right
506 Frame, Top
507 Motor Assembly, CR Carriage (CR) Motor
508 Pump Assembly
509 Cap Assembly Capping Mechanism
510 Frame, Bottom
511 Sheet, Protection, Head
512 Frame, Front
513 Bushing, Parallelism Adjustment,
Left
Left Parallelism Adjustment
Bushing
514 Bushing, Parallelism Adjustment,
Right
Right Parallelism Adjustment
Bushing
515 Paper Guide, Rear
516 Roller, PF Paper Feed (PF) Roller
517 Compression Spring, 5.85
518 Bushing, 12, Left
519 Lever, Change
520 Spur Gear, 26.4
521 Spacer, C-ring
522 Scallop Sp-AW, 2
×
16, F/B
523 Compression Spring, 0.9
Table A-28. Parts List for the Stylus COLOR 740 (continued)
Part # Parts Price List Description Common Name
