Epson STYLUS CX3650

EPSON Stylus CX3500/CX3600/CX3650/CX4500/CX4600 Revision A
PRODUCT DESCRIPTION Specifications 20
1.2.3 Common
1.2.3.1 Electric Specification
V Primary power input
Note 1: This product complies with the “Energy Star” standards.
2: If the printer is not operated at all for at least five minutes, the standby function reduces
the current to the motor to conserve power.
3: If the scanner is not operated at all for at least five minutes, the standby function
reduces the current to the motor to conserve power.
V Insulation resistance
10MΩ minimum (tested between AC line and chassis, test voltage: DC500V)
V Dielectric strength
T AC1000 Vrms for one minute or AC1200 Vrms for one second
(100-120V version)
T AC1500 Vrms for one minute (220-240V version)
1.2.3.2 Environmental Performance
Note *1: After unpacking (storage)
*2: No condensation
*3: Under the following conditions
Figure 1-8. Temperature/Humidity range
1.2.3.3 Durability
V Total print life : 10,000 pages (black only, A4), or 5 years (whichever
comes first)
V Print Head Life : 3 billion shots (per nozzle) or 5 years (whichever
comes first)
V Scanner head : MCBF (30,000 cycles)
Table 1-16. Primary power input
100-120V model 220-240V model
Rated power supply voltage (ACV) 100 ~ 120 220 ~ 240
Input voltage range (ACV) 90 ~ 132 198 ~ 240
Rated current (A)
0.4A
(max. 0.6A w/ card slot model)
(max. 0.7A w/o card slot model)
0.2A (max. 0.3A)
Rated frequency (Hz) 50 ~ 60
Input frequency range (Hz) 49.5 ~ 60.5
Power consumption (W)
Approx. 11W (w/ card slot model)
Approx. 12W (w/o card slot model)
(Standalone copying, ISO10561 Letter Patter, Plain
Paper - Text)
Approx. 2.5W (Lowe-power Mode/Sleep Mode)
Approx. 0.2W
(Power Off Mode)
Approx. 0.4W
(Power Off Mode)
Table 1-17. Environmental Performance
Condition Temperature Humidity *
2
Impact Vibration
Operating 10 ~ 35°C *
3
20 ~ 80% *
3
1G,
1 x 10
-3
seconds
0.15G
Not operating *
1
-20 ~ 40°C 5 ~ 85%
2G,
2 x 10
-3
seconds
0.50G
10
27
30
35 40
20
Temperature (°C)
20
30
40
50
90
80
70
60
Humidity (%)
