EPSON Stylus CX3500/CX3600/CX3650/CX4500/CX4600 Revision A
PRODUCT DESCRIPTION Control Panel 47
1.6.4 Printer Condition and Panel Status
Note : “–” : Don’t care
Blink : 0.5sec. On + 0.5sec. Off repetition
Blink 2 : 0.2sec. On + 0.2sec. Off + 0.2sec. On + 0.4sec. Off repetition
Blink 3 : Blink on and off along with access to a memory card.
Fast blink : 0.2sec. On + 0.2sec. Off repetition
Slow blink : 2.0sec. On + 2.0sec. Off repetition
Note *1: When the setting is “On”.
*2: After finishing copying, the counter returns to the preset number of copies.
Table 1-48. Printer Condition and Panel Status
Printer
status
Indicators
Priority
Power LED Error LED Ink LED
Memory Card LED
7-seg.
LED
Paper Type LED Paper Size LED
Fit to Page
LED
Card Access
LED
1 2 3 1 2 1 2
Power on
(Normal ready mode)
On — ————— ———— — —24
Card printing mode
(Print All/DPOF)
— — — — — On Off Selected type is On Selected size is On Off —
23
Card printing mode
(Index Sheet scanning &
printing)
— — — — On — Off Selected type is On Selected size is On Off —
Card printing mode
(Print index sheet)
— — — On — — Off On — On — Off —
Copying mode — — — Off Off Off “1~9” or “–” Selected type is On Selected size is On On *
1
—
Ink low — — Blink — — — — — — — — — — 22
PG open
(Displayed “H”)
——————
“H” blink 2
(3sec.)
———— — —
21
PG close
(Displayed “L”)
— — — — — —
“L” blink 2
(3sec.)
— — — — — —
PG error — Blink 2 — — — — “H” blink 2 — — — — — —
Index sheet error
(Incorrect card)
— Blink 2 Off — Blink 2 — “4” blink 2 — — — — — — 20
Index sheet error
(Incorrect marking)
— Blink 2 Off — Blink 2 — “3” blink 2 — — — — — — 19
To Next Page
Loading...
