Printer Specifications
A-9
R4C706
long.bk Rev. C
A5 size SPEC.FM
7/19/01
R
Proof Sign-off:
T.Kubota CRE Nakano
N.Nomoto
editorname
Mechanical
Electrical
Paper feed
method
Friction
Paper path Sheet feeder, rear entry
Sheet
feeder
capacity
About 100 sheets at 64 g/m² (17 lb) paper
Dimensions Storage
Width: 467 mm (18.4 inches)
Depth: 255.7 mm (10.1 inches)
Height: 212.1 mm (8.4 inches)
Printing
Width: 467 mm (18.4 inches)
Depth: 547 mm (21.5 inches)
Height: 302 mm (11.9 inches)
Weight 5.25 kg (11.6 lb) without the ink cartridges
120 V Model 220-240 V Model
Input voltage range 99 to 132 V 198 to 264 V
Rated frequency
range
50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.45 A 0.25 A
Power consumption Approx. 19 W (ISO10561 Letter Pattern)
Approx. 3.5 W in standby mode
