Note:
The buttons on the top control panel only affect direct printing from a
PC card.
Lights
Light Description
Processing
On when the printer is on.
Flashes when the printer is receiving data, reading data
fromaPCcard,sendingPCcarddatatothecomputer,
printing, charging ink, cleaning the print head, or when
an ink cartridge is being replaced.
b
error
On when the printer is out of paper. Load paper into the
sheet feeder, then press the
b
maintenance button to
resume printing.
Onwhenthepaperisjammed.Takeallofthepaperout
of the feeder, then reload it. If the light continues to
flash, turn off the printer and gently pull all of the paper
out of the printer.
Flashes when the black or color ink cartridge is nearly
empty.
On when the black or color ink cartridge is empty.
Replace the empty black ink cartridge or color ink
cartridge.
Black:
T007 Standard Capacity
T010 Light Capacity
Color:
T008
Flashes when the print head has moved to the ink
cartridge replacement position.
