Adjustment Details of Adjustments (TBD) 41
Epson Stylus Photo R3000 Revision A
5. Set the jig in place on the PF Roller Shaft as shown in the figure below.

Left side : Inside of PF Roller’s left end (E-ring)
 Right side : Clearance between PF Roller right end (Right Bushing 8) and left end of Upper Paper Guide
 Center : Clearance between the 2nd Upper Paper Guide and 3rd one from the left
Figure 2-5. Setting the PF Roller Shaft Position Adjustment Jig
Check for any dirt on the PF Roller Shaft when performing the following procedure.
TBD
TBD
TBD
TBD
