Rev. A Product Specifications 5-1
TM-T88II/T88III Technical Reference Guide
Chapter 5
Product Specifications
5.1 Product Specifications (TM-T88II/TM-T88III)
Table 5-1 Specifications
Print method Thermal line printing
Print width Standard: paper width of 80 mm —
print width of 72 mm {2.84"}, 512 dot positions
Factory option (with spacer): paper width of 58 mm {2.28"} —
print width of 50.8 mm {2"}, 360 dot positions
Cut type Partial cut (left-most one point uncut)
Maximum paper thickness
for the manual cutter
100 µm or less
Character sets TM-T88III: 95 alphanumeric, 37 international characters, 128 × 11 pages of
extended graphics
TM-T88II 95 alphanumeric, 32 international characters, 128 × 7 pages of
extended graphics
Interface (compatible) RS-232C/bidirectional parallel Dealer option: USB, Ethernet
Buffer Receive buffer: 4KB/45 bytes
User-defined buffer
For both downloaded bitmap images and fonts: Approx. 12KB
Macro buffer: 2KB
NV graphics data storage area: 256KB NV user memory: 1KB
DKD function 2 drives
Power supply Power supplied by optional AC adapter, PS-180 or the previous adapter, the PS-170
Operating voltage 24 VDC ± 7%
Current consumption High-speed mode
Average: TM-T88II: Approx. 1.7 A
TM-T88III: Approx. 1.8 A
(Font A, α-N, 36 capital letters, rolling pattern, 42-column printing)
Peak: Approx. 7.7 A
Low-power mode
Average: Approx. 1.2 A
(Font A, α-N, 36 capital letters, rolling pattern, 42-column printing)
Peak: Approx. 6.6 A
Standby:
Average: Approx. 0.2 A
Temperature/humidity Operating: 5 to 45°C (41 to 113°F), 10 to 90% RH
Storage: Shipped packed state –10 to +50°C (14 to 122°F), 10 to 90% RH
Weight Approx. 1.8 kg {3.968 lb}
