Rev. A Options and Consumables B-1
TM-T88II/T88III Technical Reference Guide
Appendix B
Options and Consumables
B.1 Roll Paper
The table below shows the roll paper specifications.
Note:
If roll core standards vary from the figures above, it is difficult for the roll paper NE detector to detect the
remaining amount of roll paper exactly. Use these figures merely as a guideline.
B.2 Power Supply
The following describes the specifications for the optional power supplies (PS-170 and PS-180).
B.2.1 PS-170 (Legacy Model no Longer Available from the Dealer)
B.2.1.1 Electrical characteristics
❏ Input conditions
Input voltage (rating): 90 to 264 VAC (100 VAC –10% to 230 VAC +15%)
Frequency (rating): 50/60 Hz ± 3 Hz
Power consumption (rating): 100 VA
❏ Output conditions
Output voltage (rating): 24 VDC + 5%
Output current (rating): 2.0 A
Output electric power (rating):48 VA
Output peak current: 4.5 A (within 300 msec)
B.2.1.2 Case specifications
❏ Dimensions: 80 mm (D) × 166 mm (L) × 44 mm (H) (excluding projections).
{3.15 × 6.54 × 1.73"} See the figure on the next page.
❏ Weight: Approx. 0.52 kg {1.15 lb} (excluding the AC cable)
❏ Material: Durability level: V0
❏ Color: Black (matte)
Table B-1 Paper specifications
Type of paper Specified thermal paper
Shape Roll
Paper width
Select from the following:
❐ 79.5 mm ± 0.5 mm (default)
❐ 57.5 mm ± 0.5 mm (factory option with spacer)
Roll core
Internal diameter 12 mm {0.47"}
Outer diameter 18 mm {0.71"}
External dimensions Outer diameter 83 mm {3.27"} or less
