Rev. A Options and Consumables B-3
TM-T88II/T88III Technical Reference Guide
❏ Output conditions
Output voltage (rating): 24 VDC ± 5%
Output current (rating): 2.0 A
Output electric power (rating): 48 VA
Output peak current: 4.5 A
B.2.2.2 Case specifications
❏ Dimensions: 68 mm (D) × 136 mm (L) × 32 mm (H) (excluding projections)
{2.68" × 5.35" × 1.26"} Refer to the figure below.
❏ Weight: Approx. 0.4 kg {14.11 oz} (excluding the AC cable)
❏ Material: Durability level: V0
❏ Color: Black (matte)
Figure B-2 Case specifications
B.2.2.3 Material
No specific brominated flame retardants, such as PBBE and PBB, are used in this product.
B.2.2.4 AC cable selection
❏ Select an AC cable that satisfies the following conditions.
• Safety standard product
• Plug with PE terminal
❏ Ground connection: Be sure to ground for safety.
68
32
136
To Next Page
