Rev.C Disassembly and Assembly 3-41
TM-L90 Service Manual
Confidential
11. Adjust the position of the cutter driving gear so that the triangle mark on the cutter driving
gear becomes visible through the hole in the paper cutter cover assembly.
12. Install the paper cutter cover assembly onto the cutter frame assembly.
CAUTION:
Do not pinch the lead wire between the paper cutter cover assembly and the
cutter frame assembly.
13. Tighten one manual cutter screw at on the previous page.
14. Install the manual cutter by aligning the two holes in it with the two dowels on the paper
cutter cover assembly.
15. Tighten the two manual cutter screws at on the previous page.
To Next Page
