Appendix
Printing Specifications
dpi: dots per inch
*1: When the printer prints with the standard print density level at 25°C {77°F} and 24V.
*2: The maximum is 100 mm/s {3.94"/s} when printing ladder barcodes, 2-dimensional symbols, or multi-tone graphics.
Character Specifications
Number of characters
Single-byte code characters
• Alphanumeric characters: 95
• Extended graphics: 128 × 43 pages (including user-defined page)
• International characters: 18 sets
Multi-byte code characters
• Simplified Chinese: GB18030-2000 28,553
• Traditional Chinese: Big5 13,535
• Korean: KS C5601 8,366
Paper width 58 mm Paper width 80 mm
Printing method Thermal line printing
Dot density 203 × 203 dpi
Printing width 52.5 mm {2.07"}, 420 dots 72.0 mm {2.83"}, 576 dots
Character spacing Font A 0.25 mm {0.0098"} (2 dots)
Font B 0.125 mm {0.0049"} (1 dot)
Font C 0.25 mm {0.0098"} (2 dots)
Special Font A 0.25 mm {0.0098"} (2 dots)
Special Font B 0.25 mm {0.0098"} (2 dots)
Kanji Font A 0.00 mm (0 dot)
Kanji Font B 0.00 mm (0 dot)
Line spacing 3.75 mm {1/5"} (initial setting, programmable by command)
Maximum print speed
*1
200 mm/s {5.9"/s}
*2
• The print speed changes automatically depending on the applied voltage and head
temperature.
• If the data transmission speed is slower than the maximum print speed, the print speed may
fluctuate and the print result may become shaded and/or dot displacement in paper feeding
may occur. Furthermore, if the data transmission speed is much slower than the maximum print
speed, intermittent printing will occur.
