Epson tm-m30

111
Appendix
Socket communication
For Ethernet interface
Communication specifications
10BASE-T/100BASE-TX
For Wi-Fi interface
Specification
• IEEE802.11b/g/n (2.4 GHz band) or IEEE802.11a/b/g/n (2.4 GHz or 5 GHz band) compliant
Wi-Fi communication compatible.
• Infrastructure mode and 802.11 Ad-hoc mode* are supported.
• Support the IP address automatic acquisition function (DHCP, APIPA).
*: OT-WL06 does not support Ad-hoc mode.
Communication Standard
When using OT-WL02:
• IEEE802.11b (2.4 GHz)
• IEEE802.11g (2.4 GHz)
• IEEE802.11n (2.4 GHz)
• Time out: 90 sec. (changeable)
• Job cancel: Not available
• Banner printing: Not available
• Port type TCP communication port for direct printing
• Port number 9100
• Port communication direction bidirectional
• Max. simultaneous connections 6
• Number of connections for which printing is
available
1 (Other users need to wait until the
connection is released.)
• Time out: 90 sec. (changeable)
• Countries and regions where Wi-Fi can be used are limited. Since notes are provided for each
country, check the sheet supplied with the product.
• When using wireless LAN, make sure you disconnect the LAN cable. If a LAN cable is connected,
wireless LAN is disabled.
• The combinations of wireless LAN cable set and firmware version you can use with this product are
as follows.
You can perform a firmware update by using the TM-m30 Firmware Updater if using a Windows
computer, or by using the Epson TM Utility if using a smart device. For details, see
"Utilities" on page
83
.
Wireless LAN Cable Set Firmware Version
OT-WL02 Until 1.44 ESC/POS, or 1.45A ESC/POS or later
OT-WL05 Until 1.44 ESC/POS, or 1.45B ESC/POS or later
OT-WL06 1.45A ESC/POS or later, or 1.45B ESC/POS or later
