Epson TM-P20 User Manual

Installation
This chapter describes how to install the printer drivers and conduct a test print after the installation. The
uninstallation procedure is also provided.
U See “Uninstallation” on page 48
!
Caution:
❏ Install with administrator privileges.
❏ Close all running applications before the installation.
Installation Types
You can select the installation type from the following.
❏ Easy Install: U See “Easy Install” on page 13
This is a standard installation, which installs the TM-P20 printer driver and TM-P20 Utility. If you are using a
Wi-Fi network connection, EpsonNet Config and Epson Monitoring Tool are also installed. If you are using a
Bluetooth connection, Epson TM Bluetooth Connector is also installed.
❏ Custom Install: U See “Custom Install” on page 31
You can select printer drivers and utilities you want to install. Select this installation type if you want to install the
OPOS driver, JavaPOS driver, the printer driver manual, sample programs, and tools for developing programs.
❏ Update mode: U See “Update Mode” on page 46
If the printer driver and/or UPOS is already installed, the driver version is displayed and you can select whether to
update the driver or not.
Easy Install
!
Caution:
❏ When installing, connect just one printer to the computer. Do not connect multiple printers.
❏ Turn off the printer and then start the installation.
A
Insert the TM-P20 Software & Documents Disc into the computer. The TM-P20 Software Installer is
automatically read and the EPSON TM-P20 Software Installer screen appears. Click the Install Now button.
Note:
The displayed language can be changed from Select language.
TM-P20 Software Installer Software User's Manual
Installation
13

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
