Epson TM-P20 User Manual

Click the Printing Test button. When the test print is finished, click the Finish button to end the installation.
This is the end of the printer driver installation.
Installing the OPOS ADK
A
Insert the TM-P20 Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 31
B
Check the OPOS ADK Ver.x.xx. Clear the check box for the items you do not want to install. Click the Next
button.
C
The Start Installation screen appears. The driver and utility to be installed are listed. Click the Install button to
start the installation.
D
The Choose Setup Language appears. Select your language, and click the Next button.
E
The EPSON OPOS ADK for TM-P20 Version x.xx xxx appears. Click the Next button.
F
The Software License Agreement screen appears. Read the content and select the I accept the terms in the
license agreement. Then click the Next button.
G
The Select Registry File screen appears. Click the Next button.
H
The Setup Type screen appears. Select Developer and then click the Next button.
Click the Browse button to change the default installation location.
I
The Start Copying Files screen appears. Click the Next button.
J
The Port selection screen appears. Select the port. Click the Next button to start the installation.
TM-P20 Software Installer Software User's Manual
Installation
36

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
