B
The Start Installation screen appears. The driver and utility to be installed are listed.
Click the Install button to start the installation.
C
When the installation is completed, the Installation Finished screen appears.
When conducting test print
Click the Printing Test button. When the test print is finished, click
the Finish button to end the installation.
When exiting the installation
Uncheck the Run TM-P20 Utility. Then click the Finish button to
end the installation.
When setting the printer using TM-P20 Utility
continuously
Check the Run TM-P20 Utility checkbox (the box is checked by
default). Click the Finish button to end the installation. The
TM-P20 Utility starts to run.
U See “TM-P20 Utility” on page 61
This is the end of the printer driver installation. For information on how to print using the printer driver.
U See “Using the Printer Driver” on page 54
TM-P20 Software Installer Software User's Manual
Installation
29

Epson TM-P20 Specifications

General

Type	POS printer
Color	No
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Rechargeable	Yes
Electromagnetic compatibility	FCC class A, CE
Mean cycles between failures (MCBF)	16000000
Power source type	AC, Battery
Battery life (max)	16 h
Product color	Black
Safety	EN
Country of origin	China
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	120000 h
Media thickness	0.05 - 0.08 mm
Maximum roll diameter	40.4 mm
Supported paper width	58 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g
USB connector	Mini-USB Type-B
Standard interfaces	NFC, USB 2.0
Connectivity technology	Wired & Wireless
Package depth	240 mm
Package width	195 mm
Package height	145 mm
Package weight	1482 g
Cables included	AC, USB
Quantity per pack	1 pc(s)
Operating relative humidity (H-H)	10 - 90 %
Pallet width	800 mm
Pallet height	1020 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	288 pc(s)
Quantity per pallet layer	36 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	48 pc(s)

Weight and Dimensions

Depth	120 mm
Width	79 mm
Height	44 mm
