How to use this device
10/2020 1020217-00A Operating instructions – 61/96
Maintenance performed by the studio operator or a JK Factory Certified Technician
x2
11
12
10
13
19303 / 0
Component Interval Activity See page
When necessary 300 Operating hours 500 Operating hours 800 Operating hours 1000 Operating hours 3000 Operating hours
1 Facial tanner high pressure lamps X Replace 71, 71
7 Facial tanner low pressure lamps X Replace 71
2 Shoulder tanner low pressure lamps X Replace 73
4 Low pressure lamps, base X Replace 70
5 Low pressure lamps, side section X Replace 71
8 Low pressure lamps, canopy X Replace 71
1 Starter,
low pressure lamps facial tanner
X Replace 71
3 Partition X Replace 63
2 Starter,
shoulder tanner
X Replace 73
3 Starter,
low pressure lamps, base
X Replace 70
7 Starter,
low pressure lamps, side section
X Replace 71
