3 Components
24 |
24
201000401000 / Rev 04
3.2.1 Normal Operation Mode
The primary user operates the 1-channel transmitter in normal mode.
On/Off button and function indicator LED
These are the functions of the button and function indicator LED in normal mode:
3.2.2 Firmware Update
The secondary user operates the 1-channel transmitter in the firmware update mode.
On/Off button and function indicator LED
Operation LED Status Operating Status
Switching ON to normal
operation mode
• Press On/Off button for
less than 30 seconds and
release
LED is illuminated while button
is held down
Transmitter ON, initializing
Wait for connection LED continuously flashing
twice
Transmitter waiting for con-
nection in normal operation
mode
Normal mode LED continuously flashing once Transmitter connected in
normal operation mode
Low battery voltage in nor-
mal operation mode
• Replace battery
LED continuously flashing
three times
Low battery voltage, no con-
nection possible
Switching OFF
1. Press On/Off button until
status LED is permanently
lit
2. Release On/Off button
1. LED continuously flashing in
previous mode
2. LED permanently lit
3. LED off
1. Transmitter shuts down
2. Transmitter ready for
switch-off
3. Transmitter OFF
