4 Start-up and Preparation
28 |
28
201000401000 / Rev 04
4 Start-up and Preparation
The 1-channel ECG system is, among other options, operated with the ergoline ers2 application
software. It is not possible to operate the system without software. Before use, the specially
trained ergoline service partner needs to configure the software.
If you intend to use the ECG system with a software not expressly approved by ergoline, please
contact the manufacturer of this software for information on installation, configuration, and pos-
sible restrictions.
4.1 Receiver
During commissioning, an ergoline service partner or the secondary user needs to mount and
install the receiver.
• The receiver must be mounted outside the patient environment at a minimum height of 1.5 m
with an unobstructed view of the training area. The two threaded inserts at the back of the
receiver enable the installation on a floor stand or wall bracket.
• Choose a receiver position in which the front (blue surface with status indication LEDs) is per-
pendicular and faces the training area; the cable exit is at the bottom.
• Connect the receiver to the PC system using the USB cable.
• Install the receiver driver.
• Check the installation in the Windows Device Manager.
After starting the PC system, the receiver is ready for operation. The receiver connects automati-
cally via the application software to a 1-channel transmitter that has been switched on and con-
figured appropriately.
Shutting down the PC system deactivates the receiver and terminates all connections to the
1-channel transmitters.
CAUTION Installation and instruction obligation
Incorrect installation or training may lead to wrong application of the ECG system.
The ECG system may only be used if properly installed by a certified ergoline partner and after the
user has been instructed by the certified ergoline partner.
WARNING Patient environment
The receiver must be set up outside the patient environment. The patient environment is the area
within a radius of 1.5 meters around the training device. While operating the device via the PC,
the user is not allowed to touch the patient.
CAUTION Connection quality
Improper installation of the receivers may adversely affect the connection quality.
If several receivers are used, they must be installed at a minimum distance of 50 cm from each
other.
Receivers must not be mounted directly on a metal surface.
Check the proper installation of the receivers according to the instructions in this manual.
