SPARE PARTS LIST
0449 165 160
- 56 -
© ESAB AB 2020
Item
no.
Qty Ordering no. Denomination Notes
0456 424 902 Feed unit
1 1 0455 046 003 Gear housing
2 2 0368 749 881 Pressure device
3 1 0458 997 001 Shaft
4 1 0459 001 880 Pressure arm
5 2 0458 999 001 Shaft
6 1 0458 993 001 Spring
8 4 0215 702 706 Locking washer
9 2 0458 722 001 Shaft
10 1 0380 351 001 Wire guide nipple
11 1 0455 072 001 Intermediate nozzle D13 (W)
12 1 0469 837 880 Outlet nozzle (W)
13 1 0457 365 001 Current connection
18 1 0455 048 001 Insulating tube
19 1 0455077003 Drive unit with pulse transducer
21 4 0459 441 880 Gear wheel
22 1 0459 440 001 Motor gear (W)
28 2 0458 721 001 Locking nut M6
