ESAB A2TF J1 - Page 57

SPARE PARTS LIST
0449 165 160
- 57 -
© ESAB AB 2020
Item
no.
Qty Ordering no. Denomination Notes
0457 460 881 Contact device MTW 600, 250 mm
1 1 0457 457 002 Cooling jacket
2 1 0457 455 002 Contact tube
3 1 0457 456 001 Insulation sleeve
4 1 0457 451 001 Gas nozzle
5 1 0457 452 001 Spatter protection
6 1 0457 453 001 Centering sleeve
7 1 0457 617 001 Allen screw
8 1 0457 459 001 Insulation sleeve
9 1 0457 458 001 O-ring
10 1 0457 616 880 Water hose set
11 1 0457 625 005 Contact tip Ø1.2 (W)
1 0457 625 007 Contact tip Ø1.5 (W)
1 0457 625 008 Contact tip Ø1.6 (W)
1 0457 625 009 Contact tip Ø1.8 (W)
12 0457 458 002 O-ring
13 1 0457 454 002 Wear insert (Steel spiral) L = 260, wire Ø 1.0-1.6 mm
(W)
1 0457 620 002 Wear insert (Brass tube) L = 258, wire Ø 2.0-2.4 mm
(W)
