ESAB Aristo MA4 - TIG WELDING, Panel U6

S0740 800 152/E061012/P36
-- 3 0 --
ci01i_u6tig
TIG WELDING, panel U6
Settings for TIG welding without pulsing
Settings Setting range In steps of Default setting
2/4--stroke
1)
2--stroke or 4--stroke -- 2--stroke
HF / Liftarc HF or Liftarc -- HF
Gas purging
1)
-- --
Gas pre--flow 0--5s 0.1 s 0.5 s
“Slope up” time 0--5s 0.1 s 0.0 s
”Slope down” time 0--10s 0.1 s 2.0 s
Gas post--flow 0--25s 0.1 s 5.0 s
Current
2)
4 -- 500 A 1A 100 A
T rigger data OFF,
ON or
ARC OFF
-- DISABLE
Dimensions METRIC or INCH -- METRIC
Panel enable OFF or ON -- ON
Automatic save
3)
OFF or ON -- OFF
Limits
3)
OFF or ON -- OFF
Lock code
3)
OFF or ON -- OFF
Settings for T IG welding with pulsin g
Settings Setting range In steps of Default value
2/4--stroke
1)
2--stroke or 4--stroke -- 2--stroke
HF / Liftarc HF or Liftarc -- HF
Gas purging
1)
0--5s 0.1 s 0.5 s
Gas pre--flow 0--5s 0.1 s 0.5 s
“Slope up” time 0--5s 0.1 s 0.0 s
”Slope down” time 0--10s 0.1 s 2.0 s
Gas post--flow 0--25s 0.1 s 5.0 s
Pulse duration 0.001 -- 0.1 s
0.1 --5 s
0.001 s
0.1 s
0.100 s
Background duration 0.001 -- 0.1 s
0.1 --1 s
0.001 s
0.1 s
0.200 s
Pulse current
2)
4 -- 500 A 1A 100 A
Background current
2)
4 -- 500 A 1A 25 A
T rigger data OFF,
ON or
ARC OFF
-- DISABLE
Dimensions METRIC or INCH -- METRIC
Panel enable OFF or ON -- ON
Automatic save
3)
OFF or ON -- OFF
Limits
3)
OFF or ON -- OFF
Lock code
3)
OFF or ON -- OFF
1)
These functions cannot be changed while welding is in progress.
2)
Maximal current depends on which machine type is used.
3)
Contact an authorised ESAB service engineer to activate this function.
