Fault codes for the MA4, MA6 and U6 panels
Fault codes are updated every three seconds. They are shown on the display in the form of
a symbol, as follows:
The upper figure in the symbol is the number of the particular fault code. The
lower figure indicates where the fault is:
0 = control panel 1 = cooling unit 2 = power source
3 = wire feed unit 4 = remote control unit
The above symbol show that the control panel (0) has lost contact with the power source.
Symbols may be steady or flashing, depending on the type of fault. Flashing symbols are
indicaded with “o” in the table below.
If several faults have been detected, the code of only the most recent fault is displayed.
Press any of the function keys in order to clear the symbol from the display.
Summary of fault codes
Fault
code
Description Control
panel
Cooling
unit
Power
source
Wire
feed
unit
Remote
control
unit
1 Memory error, EPROM x x x x x
2 Memory error, RAM x x x x
3 Memory error, external RAM x x x
4 +5 V power supply x x
5 Intermediate DC voltage outside limits x
6 High temperature x x
8 Power supply 1 x x x x x
9 Power supply 2 x x x
10 Power supply 3 x
11 Wire feed speed servo x
12 Communication error (warning) x x x x x
14 Communication error (bus off) x
15 Lost messages x x x x
16 High open--circuit voltage x
17 Lost contact with the wire feed unit o
18 Lost contact with the power source o
19 Incorrect setting values in external RAM x
22 T ransmitter buffer overflow x x
23 Receiver buffer overflow x x
26 Program operating fault x x x
27 Outofwire o
28 Stack overflow x x x x
29 No cooling water flow o o
31 No reply from the display unit x
32 No gas flow o
