ESAB Multimaster 300X User Manual

30
Digital Meters
Amps/Volts/WFS
Power “ON”
Lamp
Temperature
Lamp
Fault
Lamp
WFS - IPM
Lamp
Amps
Lamp
Preset
Button
Weld Process
Switch
Voltage Set - MIG
Current Set - STICK/TIG
Wire Feed
Speed Trim
IPM
Figure 12 - Control Panel
Main
Power
Switch
Spool Gun Control
Module
(Option)
Remote Control
Module
(Option)
Mig Gun
NAS
Connection
Positive Output
Connection
Negative Output
Connection
Polarity
Switching
Connector
Mig Gun Trigger
Receptacle
Figure 13 - Front Panel
SECTION 4 OPERATION
