SECTION 2 DESCRIPTION
Specications
Rated DCCV or DCCC Output (10 min base)
50% duty cycle (NEMA Class I) ..................................260 amps @ 27 vdc
Output Current Range
Mig (GMAW) ................................................................................. 35-300 amps
Tig (GTAW) .................................................................................... 10-300 amps
Stick (SMAW)................................................................................ 40-300 amps
Open Circuit Voltage
Mig (MGAW)...........................................................................................39.0 vdc
Tig (TGAW).................................................................................................20 vdc
Stick (SMAW).............................................................................................70 vdc
Primary Input Voltage & Current @ 260 amp rated load
208/230 vac, 60 Hz, 1 ph .................................................................57/52 amps
Wire Feed Range ..............................................65-675 ipm (1.6 - 17.3 m/min)
Net Weight ................................................................................250 lbs. (112.5 kg)
Shipping Weight .....................................................................290 lbs. (130.5 kg)
W x L x H ................... 25.3 in. (64 cm) x 39.5 in. (100 cm) x 33.5 in. (85 cm)
Industrial Ready-To-Weld Multi-Process Package MultiMaster® 300
Ordering Information
MultiMaster® 300 cvcc Multi-Process Packages
Each of the following packages are set ready to run .035/.045 diameter
wire. Packages include power source with built-in four roll wire feeder;
factory installed undercarriage & cylinder rack; Gun Master Mig Torch;
Gas regulator/owmeter with hose; Work cable & clamp; Primary input
cable; Mig Welding Handbook; 10# sample of .035 86HP III Wire and 5#
sample Stick Electrodes. See optional accessories.
Packages with 12ft. GM-250 Torch
0558101415 ..................................................MULTMSTR 300 230V NAS 12FT ARG
0558101416 ..................................................MULTMSTR 300 230V NAS 12FT CO2
0558101425 ..................................................MULTMSTR 300 575V NAS 12FT ARG
0558101426 ..................................................MULTMSTR 300 575V NAS 12FT CO2
Packages with 12ft. GM-250 Torch & MT-250SG
0558101418 .....................................................MM 300 230V NAS 12FT MT250-SG
0558101428 .....................................................MM 300 575V NAS 12FT MT250-SG
Packages with 12ft. GM-250 Torch & ST-23A
0558101420 ........................................................... MM 300 230V NAS 12FT ST-23A
0558101430 ........................................................... MM 300 575V NAS 12FT ST-23A
Packages with 15ft. GM-250 Torch
0558101410 ..................................................MULTMSTR 300 230V NAS 15FT ARG
0558101417 ............................................................MULTMSTR 300 230V 15FT CO2
0558101411 ..................................................MULTMSTR 300 575V NAS 15FT ARG
0558101427 ..................................................MULTMSTR 300 575V NAS 15FT CO2
Packages with 15ft. GM-250 Torch & MT-250SG
0558101419 .....................................................MM 300 230V NAS 15FT MT250-SG
0558101429 .....................................................MM 300 575V NAS 15FT MT250-SG
Packages with 15ft. GM-250 Torch & ST-23A
0558101421 ........................................................... MM 300 230V NAS 15FT ST-23A
0558101431 ........................................................... MM 300 575V NAS 15FT ST-23A
Packages with 12 or 15ft. GM-400 Torch
0558101423 .................................................MM300-GM400X12-FT, 230V ARGON
0558101424 .................................................MM300-GM400X15-FT, 230V ARGON
Packages with 15ft. GM-250 Torch & TIG/Stick w/ Remote
0558101412 .......................................................... MM300 230V DLUX MTS W/REM
0558101413 ................................................. MM300 208-575V DLUX MTS W/REM
Packages without Torch
0558101422 ................................................................ MM 300 230V W/OUT TORCH
• Advanced SuperSwitch
TM
technology makes multi-
process welding a breeze. Simplied setup makes it
easy to select Mig, Tig, or Stick
• DC welding output from 15 to 300 amps; rated 260
amps at 50% duty cycle
• Output Pre-Set Capability for Quick Set-Up
• Two Digital Meters for Easy Fine Tuning
• Heavy Duty Four Drive Roll Stand
• Convenient, Large Capacity Built-In Tool Box
• Dual “Easy-On” Cylinder Tray
• Pulse Mig Capability with optional module
