SECTION 2 DESCRIPTION
Specications
Rated DCCV or DCCC Output (10 min base)
50% duty cycle (NEMA Class I) ............................................260 amps @ 27 vdc
Output Current Range
Mig/Fluxcore (GMAW/FCAW) ..........................................................35-300 amps
Tig (GTAW) ................................................................................... 10-300 amps
Stick (SMAW) ...............................................................................40-300 amps
Open Circuit Voltage
Mig/Fluxcore (MGAW/FCAW) .......................................................................39 vdc
Tig (TGAW) ................................................................................................20 vdc
Stick (SMAW) .......................................................................................................70 vdc
Primary Input Voltage & Current @ 260 amp rated load
208/230 vac, 60 Hz, 1 ph...........................................................57/52 amps
Wire Feed Range ..................................................65-675 ipm (1.6 - 17.3 m/min)
Net Weight.....................................................................................250 lbs. (112.5 kg)
Shipping Weight ...........................................................................300 lbs. (xx.x kg)
W x L x H .......................25.3 in. (64 cm) x 39.5 in. (100 cm) x 33.5 in. (85 cm)
Ordering Information
MultiMaster
®
300X cvcc Packages
Each of the following packages are set ready to run .045" diameter
DualShield X Series wire. Packages include power source with built-in
four roll wire feeder with .045-.052-1/16" knurled feed rolls; factory
installed undercarriage & cylinder rack; Gun Master 400 Amp Mig
Torch; Contact Tips for .045", R-33-FM320 - CO2 regulator/owmeter;
6' gas hose; Electrode holder and plug; 15' Work cable & clamp; 10'
Primary input cable; Mig Welding Handbook; 33# spool of .045"
DualShield 710X wire and 5# sample assortment of Stick Electrodes.
See next page for options and accessories.
MultiMaster
®
300X w/15 ft. GM-400 “NAS” torch
208/230 vac, 1 phase 50/50 Hz. ............................................0558007778
230-575 vac, 1 phase 50/60 Hz. .............................................0558007779
If TIG Set with Thumb Control Remote is desired for the above, add one of the
TIG/Stick sets listed on the next page. If you wish to have TIG Set with Foot
Control, order one of the below outts.
MultiMaster
®
300X cvcc Multi-Process Package
MultiMaster
®
300X w/15ft. GunMaster-400 & 25ft. HW-17v2TL
208/230 vac, 1 phase 50/60 Hz ............................................. 0558007780
230-575 vac, 1 phase 50/60 Hz ...............................................0558007781
Comes complete with items listed above plus:
HW-17v-2TL Heliarc Torch, 25 ft. Heliarc Torch Accessory Kit
Remote Control Panel FC-5C Foot Control, 30 ft.
Electrode Cable & Holder, 15 ft. TIG Welding Handbook
R33-FM 580 Flowmeter/Regulator
• Advanced SuperSwitchTM technology makes welding
with DualShield X Series a breeze.
• DC welding output from 15 to 300 amps; rated 260 amps
at 50% duty cycle
• Output pre-set control with two digital meters makes for
quick set-up straight from the DualShield X Series quick
set up card.
• 400 Amp 15ft. gun set up for DualShield X Series wires in
045" and .052" diameters.
• Heavy Duty Four Drive Roll stand with serrated Du-
alShield X drive rolls for .045" and .052" dia.
• Convenient, large capacity built-in tool box
• Dual “Easy-On” cylinder tray
• Can be congured to run from Marathon paks
• Fan on demand
• Pulse Mig Capability with optional module
Industrial Ready-To-Weld Multi-Process Package MultiMaster® 300X
