The preset valu es for an u n t rimmed electronics card are sh o wn in the
following table:
Name
Trim menu
T rimming
Default values
Explanation
(meaning)
VNscale 20480 Power supply to DC bus
VXPoffset 32768 Positive voltage offset, wire feed motor
VXNoffset 32768 Negative voltage offset, wire feed motor
CXPoffset 32768 Positive current offset, wire feed motor
CXNoffset 32768 Negative current offset, wire feed motor
VYPoffset 32768 Positive voltage offset, travel motor
VYNoffset 32768 Negative voltage offset, travel motor
CYPoffset 32768 Positive current offset, travel motor
CYNoffset 32768 Negative current offset, travel motor
VXPscale 19200 Positive armature voltage measurement / speed--con-
trolled wire feed
VXNscale 19200 Negative armature voltage measurement / speed--con-
trolled wire feed
CXPscale 3200 Positive armature current measurement
CXNscale 3200 Negative armature current measurement
VYPscale 19200 Positive armature voltage measurement / speed--con-
trolled travel motor
VYNscale 19200 Negative armature voltage measurement / speed--con-
trolled travel motor
CYPscale 3200 Positive armature current measurement
CYNscale 3200 Negative armature current measurement
