6. Power source #
General
Used for Tandem welding to get both Systems to start welding at the same point.
This is only possible if the function “Weldhead offset” has been set (see on page 50).
N.B. Make sure that both control boxes have the same settings for “ Weldhead offset”
and that they have the same welding speed.
The “Master” control box is number 1 (PEH1) and the “Slave” control box is
number 2 (PEH2).
Travel motion is always steered from PEH1.
System1
(PEH1 and Welding power source no. 1)
System2
(PEH2 and Welding power source no.2)
Weldhead offset
Start sequence/ Stop sequence
S The function start sequence can be used for both System1 and System2.
N.B. The speed must be the same for both Systems.
The function stop sequence can only be used for System2.
Gas metal arc welding (GMAW)
S To use GMAW, set “Gas postflow (s)” to 1 second, see on page 47.
