ESAB RobustFeed AVS - Page 14

4  INSTALLATION
0446 680 001
- 14 -
© ESAB AB 2021
CAUTION!
Do not place heavy objects on the wire feeder when lifting. Objects should not be secured.
The lifting points are rated for a maximum total weight of 90lb / 40kg when lifted in the two
outer upper lifting handles according to the graphic above!
The 90lb / 40kg approved weight consists of wire feeder plus accessories (standard feeder
weight is 40.5lb / 18.4kg, for all weights see the TECHNICAL DATA chapter).
