Display for wire feed speed / weld current and voltage
The digital display shows the wire feed speed (in/min or m/min) / weld current and voltage. It also
enables the welder to preset wire feed speed and power source voltage.
6.4 Operating procedures
6.4.1 Weld data table
The voltage (V) and current (A) values presented in the tables below are the arc voltage and the weld
current. Values of current (A) that may flow through the wire feeder may not be higher than rated
values of the unit.
Flux Core E70T-1 and 2
Diameter
Wire Feed Speed
(inch/min) / (m/min)
150 /
3.8
200 /
5.1
250 /
6.35
300 /
7.6
350 /
8.9
400 /
10.2
450 /
11.4
500 /
12.7
600 /
15.2
.045” 29 V
150 A
29 V
210 A
30 V
250 A
33 V
290 A
34 V
330 A
.052” 25 V
155 A
30 V
300 A
1/16” 27 V
190 A
30 V
300 A
33 V
365 A
33 V
410 A
Metal Core
Diameter
Wire Feed Speed
(inch/min) / (m/min)
200 / 5.1 250 / 6.35 300 / 7.6 350 / 8.9 400 / 10.2 450 / 11.4 500 / 12.7
.045” 28 V
250 A
29 V
260 A
30 V
270 A
32 V
300 A
32 V
350 A
.052” 29 V
275 A
29 V
300 A
30 V
325 A
1/16” 30 V
300 V
30 V
350 A
32 V
400 A
Steel Solid Wire
Diameter
Wire Feed Speed
(inch/min) / (m/min)
200 /
5.1
250 /
6.35
300 /
7.6
350 /
8.9
400 /
10.2
450 /
11.4
500 /
12.7
550 /
14.0
600 /
15.2
.035” 25 V
180 A
25 V
200 A
26 V
215 A
27 V
230 A
28 V
245 A
.045” 25 V
260 A
26 V
280 A
27 V
300 A
28 V
320 A
30 V
340 A
1/16” 26 V
290 A
27 V
340 A
30 V
400 A
