5 OPERATION
0446 680 001
- 23 -
© ESAB AB 2021
5.10.2 Wire feed unit in vertical position
5.10.3 Wire feed unit in horizontal position
NOTE!
In order to attach the wire feeder to the wheel kit in the horizontal position, the two bumpers on
the wire feeder door must be removed.
