ESD CAN-DP/2 - CAN Cable Examples

Correctly Wiring Electrically Isolated CAN Networks
7.5 Examples for CAN Cables
7.5.1 Cable for Light Industrial Environment Applications (Two-Wire)
Manufacturer Cable Type
U.I. LAPP GmbH
Schulze-Delitzsch-Straße 25
70565 Stuttgart
Germany
www.lappkabel.com
e.g.
UNITRONIC ®-BUS CAN UL/CSA (1x 2x 0.22)
(UL/CSA approved) Part No.: 2170260
UNITRONIC ®-BUS-FD P CAN UL/CSA (1x 2x 0.25)
(UL/CSA approved) Part No.: 2170272
ConCab GmbH
Äußerer Eichwald
74535 Mainhardt
Germany
www.concab.de
e. g.
BUS-PVC-C (1x 2x 0.22 mm²) Order No.: 93 022 016 (UL appr.)
BUS-Schleppflex-PUR-C (1x 2x 0.25 mm²) Order No.: 94 025 016 (UL appr.)
7.5.2 Cable for Heavy Industrial Environment Applications (Four-Wire)
Manufacturer Cable Type
U.I. LAPP GmbH
Schulze-Delitzsch-Straße 25
70565 Stuttgart
Germany
www.lappkabel.com
e.g.
UNITRONIC ®-BUS CAN UL/CSA (2x 2x 0.22)
(UL/CSA approved) Part No.: 2170261
UNITRONIC ®-BUS-FD P CAN UL/CSA (2x 2x 0.25)
(UL/CSA approved) Part No.: 2170273
ConCab GmbH
Äußerer Eichwald
74535 Mainhardt
Germany
www.concab.de
e. g.
BUS-PVC-C (2x 2x 0.22 mm²) Order No.: 93 022 026 (UL appr.)
BUS-Schleppflex-PUR-C (2x 2x 0.25 mm²) Order No.: 94 025 026 (UL appr.)
Note:
Configured CAN cables can be ordered from esd.
Page 24 of 34
Hardware Manual • Doc. No.: C.2907.21 / Rev. 1.1
CAN-DP/2, CANopen-DP/2
