7. Dimensions
7.1. Exterior
*Including Height of Circulation Fan Motor.
7.2. Interior
Model Width Depth Height
ESZ-2C
19.69 in.
500 mm.
23.89 in.
607 mm.
29.53 in.
750 mm.
ESZ-3C
23.62 in.
600 mm.
31.77 in.
807 mm.
33.47 in.
850 mm.
ESZ-4C
39.37 in.
1000 mm.
35.47 in.
901 mm.
39.37 in.
1000 mm.
8. Utilities Required
8.1. Electric
Minimum Service Current (Recommended Value)
8.2. Condensate Drain Tube Size: 1/2” I.D.
8.2. Refrigeration Cooling
8.2.1. Water Cooled Specific
(minimum 30 psi differential pressure,
Maximum supply pressure 90 psi.)
8.2.2. Air Cooled Specific Air Cooled Heat Rejection to Ambient: 25,000 Btu/Hr.
8.3. Operation Noise Levels Measure 1M away from Chamber and 1M Above Floor.
( ) = Water Cooled Models
9. Construction
9.1. General Material
9.1.1. Exterior Stainless Steel Sheets, 18GA (SS430).
9.1.2. Interior Stainless Steel Sheets, 20GA (SS304).
9.1.3. Insulation Fiber Glass and Foam Glass.
9.1.4. Thermal Break Support Frame Molded Unsaturated Polyester Resin.
9.1.5. Gasket Silicone.
9.2. Door
9.2.1. Door Handle Recessed Door Handle on Right Side and Hinges on Left.
9.3. Heater Nichrome Wire Heater at 208V
Model Heater
ESZ-2C 3 KW
ESZ-3C 3 KW
ESZ-4C 6 KW
9.4. Cooler Aluminum Fin Coil.
9.5. Circulator Sirocco Fan.
Model Width Depth Height* Weight
ESZ-2C
36.43 in.
925 mm.
47.08 in.
1196 mm.
76.15 in.
1934 mm.
840 lbs.
382 kg.
ESZ-3C
41.37 in.
1051 mm.
55.01 in.
1397 mm.
80.08 in.
2034 mm.
920 lbs.
418 kg.
ESZ-4C
57.24 in.
1454 mm.
58.66 in.
1490 mm.
86.11 in.
2187 mm.
1095 lbs.
498 kg.
ESZ-2C ESZ-3C ESZ-4C
208/230V 3PH 60Hz 40 A 40 A 50 A
Temp. 75°F
(GPM)
Temp. 85°F
(GPM)
Connection
Size (NPT)
Heat Rejection
Rate to Water
2.2 3.4 1/2”
≈ 25,000 Btu/Hr.
Model
Operator Area
Ref. ON
Maximum
Ref. ON
Maximum
Ref. OFF
ESZ-2C 72 (70) dBA 76 (75) dBA 60 dBA
ESZ-3C 72 (70) dBA 76 (75) dBA 60 dBA
ESZ-4C 72 (70) dBA 76 (75) dBA 60 dBA
