Essilor Instruments AKR 300 User Manual

1. Main unit
No. Name Function
1 Measurement head Unit that performs measurement.
2 Height adjustment mark
Align the height of the examinee's eye with this mark by
adjusting the height of chinrest.
3 Monitor
Monitor that displays measurement and [SET] modes
displays.
4 Printer Print the measured result.
5 Stage holding lever Holds the movement of stage (sliding table).
6 Operation lever Use this lever for alignment and focusing.
7 Chinrest lever Align the height of chinrest up and down.
8 Measuring button Press this button for measurement.
USER MANUAL > DESCRIPTION
AKR300 - Auto Kerato Refractometer > V3 - 04-2020
14
