Chapter 3 Parameter Description of Machine Tool
3.1 Enter parameter page
Steps to entering parameter page are as below.
Step 1 Power on, and press two times to enter Programming Constant page, as shown
in Figure 3-1. On this page, program constant can be set.
CONST
mm/inch: 0
中文/English: 1
Release Time: 0.30
Version: 1.11
0: mm 1:inch
Pulse Time: 0.200
Figure 3-1 Program Constant page
Step 2 Move the cursor to parameter mm/inch or 中文/English, and input the password
14789, press to enter Parameter Setting page, as shown in Figure 3-2.
1. SYSTEM PARA
2. X AXIS PARA
Press ‘NUM’ Enter
PARAMETER
3. Y AXIS PARA
4. BACKUP/LOAD
Figure 3-2 Parameter Setting page
Step 3 Select “1. System Parameter”, then press to enter system Parameter Setting
page, as shown in Figure 3-3.
SYS PARA 1/ 1PG
X-digits: 1
Range: 0~3
Y-digits: 2
X-safe: 10.0
Y-safe: 5.00
Step delay: 0.5
Count Select: 0
LDP Enable: 0
Figure 3-3 System Parameter Setting page
To Next Page
