Chapter 1 Specification
1.1 Display
LCD display
Dimension of display window: 54.38mm*54.38mm
Dot matrix: 160*160
Status light
Green indicates running
Red indicates stop
1.2 Internal memory
Capable of storing 40 programs, each program includes 25 steps at most.
1.3 Electrical specification
POWER
Input voltage: DC24V±10%
Rated current: 1A
INPUT
Input voltage: DC24V±10%
Maximum input current: 10mA
OUTPUT
External voltage: DC24V±10%
Maximum current: 70mA
Encoder power
Output voltage: DC12V±5%
Allowable maximum output current: 500mA
Absolute temperature
Working temperature: 0～40℃
