27
Over.Dis.: 5.00
Repeat Enable: 1
Repeat Time: 1.00
Stop Dis.: 100
Mute Dis.: 4000
Overrun En.: 0 (Bilateral orientation is enabled)
Y-Axis parameter setting
Y-axis parameter setting: the method is similar to the setting of X axis parameter
5.2.2 Action commissioning
Press “+” to observe whether X axis moves backward. If the moving direction is
opposite, then adjust phase sequence of X axis motor.
Make sure whether counting direction of encoder is correct. If it is incorrect, revise
Parameter-encoder direction.
Press “-”and “++--”to make sure whether opposite direction moving and high speed
moving is correct.
Make sure whether front and rear limit function in correct way.
5.2.3 Precision commissioning
When Repeat Enable is 0: utilize single step procedure, to modify X axis setting
position from big to small. Press “Running” key to move X axis from back to front. If
the location after positioning beyond the setting location, then the Stop Dis.
parameter will be decreased; otherwise, the Stop Dis. parameter will be increased.
This process may be adjusted many times until the difference between actual
location and setting location is less than 0.1.
When Repeat Enable is 0: utilize single step procedure, to modify X axis setting
position from big to small. Press “Running” key to move X axis from back to front. If
the location after positioning beyond the setting location, then the Over.Dis.
parameter will be decreased; otherwise, the Over.Dis. parameter will be increased.
This process may be adjusted many times until the difference between actual
location and setting location is less than 0.1.
When Repeat Enable is 1: over travel enable shall be set to 1, setting over travel
distance shall exceed advance stop range. Start system, and observe whether
system will return to over travel distance and start to position after fail to reach
tolerance range in completion of positioning.
